Ortofon MC Windfeld Ti Cartridge

Ortofon MC Windfeld Ti Cartridge

The Ortofon MC Windfeld Ti Cartridge is available for demonstration in our Hull store by request.

The MC Windfeld Ti is a moving coil cartridge built into a new and improved cartridge body. Sharing similarities with the high-end Cadenza Series, the central band of the MC Windfeld Ti body is made using a revolutionary Selective Laser Melting manufacturing technology, also used by Ortofon on the flagship MC Anna cartridge. The technology uses Titanium to increase the overall rigidity of the cartridge body, eliminating unwanted vibrations within the cartridge and increasing the dynamic capability.

Like the flagship MC Anna cartridge, the Ortofon MC Windfeld Ti makes use of “the finest diamond in the world”. The Ortofon Replicant 100 boasts a thin and light profile with an impressively long vertical contact surface, making it as close as possible to an original record cutting stylus. By specially polishing the stylus and then mounting it onto a boron cantilever, the cartridge can offer remarkable transparency, speed, and responsiveness beyond that of any other combination.

The MC Windfeld Ti stylus and cantilever are connected into a compact, lightweight generator system based around a powerful neodymium magnet and Ortofon's Aucurum 6NX oxygen-free copper coil wire. The specially designed armature used inside the system has low magnetic properties for uninhibited tracking of the cantilever’s movements. An additional Field-Stabilizing Element is also placed inside the system to prevent the magnetic field from fluctuating, which allows for improved channel separation, zero transmission loss and greater sound-staging with more space between the performers.

The cantilever also passes through a suspension system aided by Ortofon’s Wide Range Damping system, in which a small, heavy platinum disc is sandwiched between two rubber absorbers with different properties for exceptional tracking performance and perfect damping throughout the frequency range. This helps the Ortofon MC Windfeld Ti deliver a distortion-free performance with an exceptionally linear frequency response.

Thanks to these advanced properties, the MC Windfeld Ti is a cartridge that delivers a lifelike, dynamic and open sound with exceedingly clear midrange. Yet even though it retrieves the finest micro-dynamic details, the whole performance is delivered in a delicate, extremely musical tone.

Part Exchange Available

As you would expect from Fanthorpes hifi, we offer a generous part exchange against the Ortofon MC Windfeld Ti Cartridge. If you have any hifi that you wish to use as part payment then either call us on 01482 223096 or email us at shop@fanthorpes.co.uk and we will give you a price to change. This is a fantastic and hassle-free way of making the Ortofon MC Windfeld Ti more affordable.

Finance Available

Fanthorpes hifi can also offer buy now pay later on the Ortofon MC Windfeld Ti Cartridge, allowing you to spread or defer your payments over a year. If you are interested in taking advantage of our payment terms, email shop@fanthorpes.co.uk or call us on 01482 223096 and we will email an application form to you.

Ortofon MC Windfeld Ti Cartridge Specification:

• Output Voltage (at 1kHz, 5cm/sec): 0.2mV
• Channel Separation at 1kHz: 25dB
• Channel Separation at 15kHz: 20dB
• Frequency Range (at -3dB): 10Hz - 50kHz
• Frequency Response: 20Hz - 20kHz +2/-1dB
• Tracking Ability at 315Hz: Typically 90μm
• Compliance, Dynamic, Lateral: 13μm / mN
• Stylus Type: Nude Ortofon Replicant 100
• Special Polished Version
• Cantilever: Boron
• Stylus Tip Radius r / R: 5 / 100μm
• Tracking Force Range: 2.0 - 2.5g (20 - 25mN)
• Recommended Tracking Force: 2.3g (23mN)
• Tracking Angle: 23º
• Internal Impedance / DC Resistance: 7Ω
• Recommended Load Impedance: 10Ω
• Cartridge Body Material: SLM Titanium, Stainless Steel
• Cartridge Colour: Titanium / Black
• Cartridge Weight: 11.0g
• Channel Balance at 1kHz: 0.5dB
