Lyngdorf MXA-8400 Multi Channel Amplifier

Lyngdorf MXA-8400 Multi Channel Amplifier

The Lyngdorf MXA-8400 Multi Channel Amplifier is a meticulously crafted 8-channel power amplifier designed to deliver exceptional audio performance. Manufactured at the Lyngdorf Audio facility in Denmark, each unit undergoes stringent quality control measures, including a rigorous 24-hour test with all channels driven. This exhaustive testing process is crucial to guarantee the amplifier's reliability and adherence to specified performance parameters.

With a power rating of 8 x 400 W @4Ω in 2-CHANNEL mode, 8 x 200 W @8Ω in 2-CHANNEL mode, and 4 x 800 W @8Ω in BRIDGE mode, the MXA-8400 showcases its capability to handle various audio setups. Its power rating at rated THD, low idle power consumption of 29 W, and standby power consumption of less than 0.5W contribute to its efficiency and energy-conscious design. The amplifier features a swift 15-minute transition to standby mode in the absence of input signals, especially in its LOW POWER mode.

Ensuring precise and accurate audio reproduction, the MXA-8400 boasts a frequency response of ±0.1dB (ref. 20Hz-20kHz) and a minimal total harmonic distortion (THD) of 0.001% @200 W, 8Ω / 340 W, 4Ω, 20Hz-20kHz. The amplifier's gain settings, signal/noise ratio of 128dB (A-weighted ref. rated power, LOW Sensitivity mode), and a damping factor exceeding 1200 (8 Ω, 20Hz-1kHz) underline its commitment to delivering a superior audio experience. Furthermore, the MXA-8400 is equipped with practical features such as multiple audio inputs and outputs, including 8 x XLR analog inputs and 8 x Neutrik speakON outputs, making it a versatile choice for various audio setups. The sleek matte black finish adds a touch of elegance to its functional design, making the MXA-8400 a reliable and aesthetically pleasing addition to any audio system.

Part Exchange Available

As you would expect from Fanthorpes hifi, we offer a generous part exchange against the Lyngdorf MXA-8400 Multi Channel Amplifier. If you have any hifi that you wish to use as part payment then either call us on 01482 223096 or email us at shop@fanthorpes.co.uk and we will give you a price to change. This is a fantastic and hassle-free way of making the Lyngdorf MXA-8400 Multi Channel Amplifier more affordable.

Finance Available

Fanthorpes hifi can also offer buy now pay later on the Lyngdorf MXA-8400 Multi Channel Amplifier, allowing you to spread or defer your payments over a year. If you are interested in taking advantage of our payment terms, email shop@fanthorpes.co.uk or call us on 01482 223096 and we will email an application form to you.

Lyngdorf MXA-8400 Multi Channel Amplifier Specifications:

• Description: 8-channel power amplifier
• Power rating: 8 x 400 W @4Ω (2-CHANNEL mode), 8 x 200 W @8Ω (2-CHANNEL mode), 4 x 800 W @8Ω (BRIDGE mode)
• Power rating at rated THD: 8 x 340 W @4Ω (2-CHANNEL mode), 8 x 200 W @8Ω (2-CHANNEL mode)
• Idle power consumption: 29 W
• Standby power consumption: <0.5W
• Time to standby mode: 15 minutes (at no input signal, in LOW POWER mode)
• Frequency response: ±0.1dB (ref. 20Hz-20kHz)
• THD: 0.001% @200 W, 8Ω / 340 W, 4Ω, 20Hz-20kHz, 0.0006% @10 W, 4Ω, 20Hz-20kHz, LOW Sensitivity mode, 0.0007% @10 W, 4Ω, 20Hz-20kHz, HIGH Sensitivity mode
• Max output current per channel: 25A
• Max output voltage per channel: 58V peak (2-CHANNEL mode), 116V peak (BRIDGE mode)
• Gain: HIGH Sensitivity mode: 26.1 dB (2-CHANNEL mode), 31.7 dB (BRIDGE mode), LOW Sensitivity mode: 16.6 dB (2-CHANNEL mode) 22.2 dB (BRIDGE mode)
• Signal/noise ratio: 128dB (A-weighted ref. rated power, LOW Sensitivity mode)
• Damping factor: >1200 (8 Ω, 20Hz-1kHz)
• Input sensitivity: HIGH Sensitivity mode: 2V, LOW Sensitivity mode: 6V
• Input impedance: 10 kΩ
• Audio inputs: 8 x XLR analog inputs
• Audio outputs: 8 x Neutrik speakON
• Dimensions (W x H x D): 45 x 14.5 x 34.9 cm / 17.7 x 5.7 x 13.7 inches
• Weight: 10.3 kg / 22 lb
• Finish: Matte black
